Casa ProdutosArmário da cremalheira do servidor19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard

19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard

19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard
19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard
Informação Básica
Lugar de origem: China
Marca: LE or OEM
Certificação: CE ROHS
Número do modelo: LE-ND
Quantidade de ordem mínima: 10 unidades
Preço: USD90-250
Detalhes da embalagem: Embalagem montada ou embalagem plana
Tempo de entrega: 30-45 dias
Termos de pagamento: L/C,D/A,D/P,T/T,Western Union
contacto
Material: Aço laminado a frio de qualidade SPCC Grossura: Profil de montagem: 2,0 mm, outros: 1,2 mm
Espessura do vidro temperado: 5mm Capacidade de carga: Carga estática: 800 kg (nos pés ajustáveis)
Grau de proteção: IP20 Acabamento de superfície: Desengraçamento, decapagem, fosfatagem, revestimento em pó
Especificação do produto: 18U-47U largura: 600mm, 800mm
Profundidade: 600 mm, 800 mm, 900 mm, 1000 mm, 1200 mm Cor: RAL9004, RAL9005, RAL7035

19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard


General Description:


1. Classic model, disassembled structure, can be flat packing and easy to transport.
2. Tempered glass front door, vented door, dual open vented door are available.
3. Removable side panel with latches, easy to install, optional lock;
4. Cable entry on the top and bottom, easy to manage cable;
5. Adjustable feet and castors are available simultaneously.
6. S-shaped mounting profile, free to move forward and back.
7. Various optional accessories for common using.

SS/N S/N /N S/N
LE-ND
Material
SPCC quality cold rolled steel;
Mounting profile: Thickness:2.0mm,others:1.2mm
Loading Capacity
Static loading: 800kg(on the adjustable feet)
Degree of protection
IP20
Surface Finish
Degreasing; Pickling; Phosphating; Powder Coated
Product Specification
18U-47U
Width: 600mm,800mm
Depth: 600mm,800mm,900mm,1000mm,1200mm
Color: Ral9004; Ral9005; Ral7035














19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 0

19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 1


19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 2

19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 3

19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 4

FAQ
1. Q: Are you a factory or trading company?
A: We are a Factory, Distributor and Trading Company.
2. Q: Where is your factory located? How can I visit there?
A:Our factory and office is located in Ningbo City, China. You can fly to Ningbo airport or Shanghai airport, from home or abroad,
are warmly welcome to visit us!
3. Q: Can you do OEM?
A: Yes, we can do OEM products. It's no problem.
4. Q: How can I get some samples?
A: We are honored to offer you samples.
5. Q: How does your factory do regarding quality control?
A:Quality is priority.We always attach great importance to quality controlling for to the every end. Our factory has gained
CE,ROHS,SGS authentication.

19" Standard Dual-open Vented Door with Handle Locks 42U 600mm 800mm Width 600mm-1200mm Depth RAL9004 Black Complay ANS/EIA RS-310-D, IEC297-2, DIN41497 PART 1, DIN41494 PART 7, GB/T3047.0-92 Standard 5
