| Nome do produto:: | rack de servidor 12u gabinete de montagem em parede de rack de rede de 10 polegadas | Tipo:: | Gabinete de rede para montagem em parede |
|---|---|---|---|
| Série de cores:: | Ral9004; Ral9005; Ral7035 | Altura:: | 4U 6U 9U 12U |
| Espessura Matcial:: | 1,2 mm | Capacidade de carregamento:: | Carga estática: 15 kg |
| Grau de proteção:: | IP20 | Acabamento de superfície:: | Desengraçamento, decapagem, fosfatagem, revestimento em pó |
| Aplicativo:: | Expedição de cabogramas da rede | Destaque:: | Rack de servidor de fonte de alimentação estável PDU, rack de servidor durável PDU, equipamento de p |
S/N LE-MW Standard Comply with ANS/EIA RS-310-D, IEC297-2, DIN41491, PART1, DIN41491, PART7, ETSI Standard Material SPCC quality cold rolled steel: Thickness:1.2mm; Tempered glass: Thickness:5.0mm Loading Capacity Static loading: 15kg Degree of protection IP20 Surface Finish Degreasing; Pickling; Phosphating; Powder Coated Product Specification 4U 6U 9U 12U Width: 325mm Depth: 300mm Main Structure 1. Installing Backboard 2. Mounting profile (L-shaped) 3. Cable entry plate 4.
